ZEISS: Advanced Packaging Analysis Solutions

With the slowing of Moore’s Law, there has never been more urgency to address challenges for integrated circuit (IC) package characterization and failure analysis (FA) in the More than Moore (MtM) era. Diverse IC package strategies exist to enable the highest system performance. As a result, package developers and failure analysts are faced with complex package architectures, shrinking package interconnect pitches on the order of a few microns, and system-on-chip (SOC) disintegration, which leads to larger package footprints approaching 100mm x 100mm or larger. These trends drive requirements for new capabilities across the entire FA workflow.

With this in mind, we invite you to join our webinar entitled “ZEISS Advanced Packaging Analysis Solutions”, where we will provide an insight on New ZEISS solutions addressing MtM IC package analysis challenges for 3D X-ray imaging and a “Packaging FIB”, the Crossbeam laser. These technologies represent significant advancements for the package FA workflow.

This session is designed for those working in Electronics Materials Characterization, Electronics Failure Analysis & Electronics Packaging, with key learnings including:

• An introduction to the “More-than-Moore” (MtM) packaging trend
• How 3D X-ray microscopy is used to address the challenge of MtM package analysis
• Technical highlights of the ZEISS “Packaging FIB” for improvement of FA workflow
